WE310F5 / WE310G4
Cost Effective
The WE310F5 series is a fast and cost-effective Wi-Fi module for product design.
Telit Cinterion offers a product portfolio including IoT modules and IoT platforms compatible with various networks such as cellular (LTE, 5G), LPWA, and WiFi. Our strength lies in providing end-to-end support for customers' IoT service deployment, extending to applications and management tools operating on the cloud side.
With nearly 20 years of IoT innovation, Telit Cinterion delivers secure, end-to-end integrated IoT solutions to global industry leaders across enterprises, OEMs, system integrators, and service providers. We drive digital business by contributing to corporate digital transformation.
For more details on Mobile Broadband and 5G
| Product Images |  |
 |
 |
 |
|---|---|---|---|---|
| Product Name | LN920A6/12※In Plan | LM960A18 | FN980 | FN982m |
| Form Factor | M.2(NGFF) | mPCIe | M.2(NGFF) | M.2(NGFF) |
| Speed | 600/100 Mbps | 1.2G/150 Mbps | Sub6 : 3.8G/542Mbps | Sub6 : 3.8G/542Mbps |
| Size | 30 x 42 x 2.3 mm | 30 x 50 x 2.7 mm | 30 x 50 x 3.4 mm | 30 x 42 x 2.6 mm |
| GNSS | Yes (GPS, GLONASS, Beidou ,） | Yes (GPS, GLONASS, Beidou ,） | Yes (GPS/Glonass/ Beidou/Galileo) |
Yes (GPS/Glonass/ Beidou/Galileo) |
| Approvals | CE/RED, FCC/IC, JATE/TELEC, NCC, RCM,GCF, PTCRB | FCC,PTCRB, RED, GCF,JATE/TELEC, IC, | FCC, RED, GCF, PTCRB,JATE/TELEC, IC, | FCC, RED, GCF, PTCRB,JATE/TELEC, IC, |
| Voice | Data only | Data only | Supported | Supported |
| Power Supply | 3.1 -3.6 VDC (Typ. 3.3V) |
3.1 -3.6 VDC (Typ. 3.3V) |
3.1 -3.6 VDC (Typ. 3.3V) |
3.1 -3.6 VDC (Typ. 3.3V) |
| Interface | USB 3.0, GPIOs | USB 3.0, GPIOs | PCIe gen 3 + USB 3.1 | PCIe gen 3 + USB3.0 |
| Temperature | -40 °Cto + 85°C | -40 °Cto + 85°C | -40 °Cto + 85°C | -40 °Cto + 85°C |
| Driver Support | Windows, Linux | Windows, Linux | Linux, Android | Windows, Linux |
For more details on Cellular 5G, 4G LTE, 3G & 2G
| Product Name |  |
 |
 |
|---|---|---|---|
| Cellular | xE310 Family | xL865 Family | xE910 Family |
| 4G LTE Cat 4 | - | - | LE910C4 Series |
| 4G LTE Cat 1 | - | - | LE910C1 Series / LE910S1 Series |
| 4G LTE LTE-M / NB-IoT | ME310G1 Series | ML865C1 Series / ML865G1 Series | ME910C1 Series ME910G1 Series |
| 4G LTE NB-IoT | NE310H2 Series / NE310L2 Series | NL865H2 Series | - |
| 3G UMTS / HSPA | - | UL865 Series NRND | HE910 Series UE910 Series NRND |
| 2G GSM / GPRS | GE310-GNSS | GL865-DUAL V3/V3.1 GL865-QUAD V3/V3.1 GL865-QUAD V4 | GE910 Series |
Telit Cinterion's Wi-Fi and Bluetooth modules provide solutions that reduce customer development time and shorten time-to-market. Additionally, Telit Cinterion products comply with industry standards, global specifications, and industry certification requirements.
WE310F5 / WE310G4
Cost Effective
The WE310F5 series is a fast and cost-effective Wi-Fi module for product design.
WE866C6
Cellular Companion
With its small footprint and rich features, it is ideal for network applications such as smart energy, sensor networks, and home automation.
*You can swipe left and right on the table below.
| Product Name | WE310F5 series | WE310G4 series | WE866C6 | |||
|---|---|---|---|---|---|---|
| WE310F5-P | WE310F5-I | WE310G4-P | WE310G4-I | WE866C6-P | ||
| Form Factor | LGA | LGA | LGA | LGA | LGA | |
| Product Image |  |
 |
 |
|||
| Size | 14.3 x 13.3 x 2.6 mm | 18 x 15 x 2.6 mm | 14.3 x 13.3 x 2.6 mm | 18 x 15 x 2.6 mm | 15 x 13 x 2.2 mm | |
| Chip Antenna | ― | 〇 | ― | 〇 | ― | |
| Wi-Fi Standard | Wi-Fi 802.11 b/g/n(Wi-Fi 4) | Wi-Fi 802.11 a/b/g/n(Wi-Fi 4) | Wi-Fi - 802.11 a/b/g/n/ac (Wi-Fi 5) |
|||
| Frequency Band | 2.4 GHz | 2.4 GHz / 5 GHz | 2.4 GHz / 5 GHz | |||
| Stream | 1 x 1 | 1 x 1 | 1 x 1 | |||
| Solution Architecture | Hosted (AT commands) or Standalone (host-less) |
Hosted (AT command) or Standalone (hostless) |
1:Companion module for LTE modules (AT commands) 2:Linux-based system for Wi-Fi module Standalone usage |
|||
| Host Interface | UART, SPI, SDIO, USB | UART, SPI, SDIO, USB | SDIO, UART | |||
| Firmware Upgrade | FOTA | FOTA | FOTA | |||
| Bluetooth | BLE 5.0 | BLE 5.0 | Bluetooth & BLE 5.0 | |||
| Approvals | TELEC | 〇 | ― | 〇 | ||
| Other | FCC/IC/RED/RCM/JATE-JBL/TELEC-JRL/NCC/ ANATEL/SRRC/WPC-ETA/ KCC/UKCA |
FCC/ISED/RED | FCC, IC, RED, UKCA, TELEC, ANATEL, MPC, WPC-ETA | |||
| Power Supply(VDC) | 3.3 V | 3.3 V | 3.3 V | |||
| Operating Temperature | -40 °C ~ +85 °C | -40 °C ~ +85 °C | -40 °C ~ +85 °C | |||
| LTE-Wi-Fi Bundling |
Architecture | ― | ― | Hosted (AT commands) | ||
| Supported LTE Modules |
― | ― | LE910C4/C1-NF LE910C4/C1-EU LE910C4/C1-LA LE910C4/C1-AP LE910C4-CN LE910C1-NA/NS |
|||
